TrailMaster TM31 250cc Dirt Bike 5-Speed Manual Dual Disc Brakes, Electric Start with Kick backup (19/16) – Green

TM31 has a High-performance 223cc 16hp engine with Electric Start with Kick backup, a top speed of around 56mph, a seat height of 34.6”, 5-speed manual transmission, front and rear disc brakes, inverted front shock, and a lightweight steel tube frame!
The bikes’ full on motocross ergonomics with a 19” front / 16” rear wheel and race suspension system, make handling feel natural and unforced, and help it navigate over almost any type of terrain. Electronic Digital CDI ignition makes key and kick starting effortless, keeps the bike running smoothly in all gears and provides a broad, even power band. And at only 297 pounds, the 223cc engine can propel the motorcycle to speeds of 56 miles per hour.
Specifications
Engine Type ZSCB250D-G, Single Cylinder, 4-Stroke, Air Cooled
Displacement 223 cc
Max Power 16 hp
Max Torque 17.5/5500 N.m/r/min
Compression Ratio: 9.3~9.9:1
Shift Type: Manual Wet Multi-Plate, 1-N-2-3-4-5, 5-Gears
Bore and Stroke: 65.5 x 62.2 mm
Min. Fuel Consumption: ≤354(g/Kw.h)
Start Type Electric & Kick Start
Carburetor PE28
Ignition Digital CDI
Transmission #520 Chain, FT: 13T/RR: 47T Sprocket
Dimensions
Front Fork 51*54-830mm Inverted Hydraulic Forks, 150mm Travel
Rear Shock 450mm Spring Pre-load None-Adjustable Shock
Front Wheel Aluminum Rim, Gravity Cast Hub, FT: 1.6 x 19
Rear Wheel Aluminum Rim, Gravity Cast Hub, RR: 2.15 x 16
Front Tires 70/100-19 Rear Tires 90/100-16
Front Brake Dual Piston Caliper, 240mm Disc
Rear Brake Single Piston Caliper, 240mm Disc
Frame/Suspension/Brake System
Frame: Lightweight, Steel Tube Frame
Swing-Arm: Tube High Strength Steel Swingarm: L=560mm
Handlebar: Tapered Aluminum #6061
Overall Size: 78″X32″X45.7″
Packing Size: 67.3″X17.5″X34″
Wheelbase: 53.1″
Seat Height: 34.6″
Ground Clearance: 13″
Fuel Capacity 2 Gal.
N.W 231lbs G.W 297lbs
